Task Checklist in Events

When there are subtasks related to work orders, it may be necessary to display them in the context of work order (or event). Subtasks can be rendered as a list with the possibility of adding new items using the Prompt or more sophisticated modals even. The height of resources will dynamically increase depending on the height of the events/length of lists.

To allow dynamic changes in heights according to the length of subtask lists, eventHeight: 'variable' is used, along with custom event content templating to maintain the appropriate theme styles.

Get started with this example

Demo

Loading the live demo

Preview in full screen

Render a task checklist inside each Timeline event card — row heights expand as the list grows, and a popup let users add new subtasks.

Code

View code on GitHub
import { CommonModule } from '@angular/common';
import { HttpClient } from '@angular/common/http';
import { Component, OnInit } from '@angular/core';
import {
  MbscCalendarEvent,
  MbscCalendarEventData,
  MbscEventcalendarOptions,
  MbscModule,
  MbscResource,
  Notifications,
  setOptions ,
} from '@mobiscroll/angular';

setOptions({
  locale:  ,
  theme: ' ',
  themeVariant: ' '
});

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  providers: [Notifications],
  standalone: true,
  imports: [CommonModule, MbscModule],
})
export class AppComponent implements OnInit {
  constructor(
    private http: HttpClient,
    private notify: Notifications,
  ) {}

  calendarOptions: MbscEventcalendarOptions = {
    dragToCreate: true,
    clickToCreate: true,
    dragToMove: true,
    dragToResize: true,
    view: {
      timeline: {
        type: 'week',
        eventHeight: 'variable',
        eventDisplay: 'fill',
      },
    },
    extendDefaultEvent: () => ({
      title: 'New Event',
      tasks: ['Default task'],
    }),
  };

  myEvents: MbscCalendarEvent[] = [];

  myResources: MbscResource[] = [
    {
      id: 1,
      name: 'Site Plumbing Squad',
      description: 'Elite construction plumbers ensuring flawless pipeline installations on every site.',
      color: '#01adff',
    },
    {
      id: 2,
      name: 'Pipeline Builders',
      description: 'Constructing fluid pathways, one precision connection at a time.',
      color: '#239a21',
    },
    {
      id: 3,
      name: 'Blueprint Plumbers',
      description: 'Turning plans into precise pipelines with expert craftsmanship.',
      color: '#ff4600',
    },
    {
      id: 4,
      name: 'Site Supply Specialists',
      description: 'Delivering essential plumbing materials promptly to construction sites',
      color: '#4981d6',
    },
    {
      id: 5,
      name: 'Infrastructure Installers',
      description: ' Building the backbone of modern plumbing systems efficiently.',
      color: '#f1e920',
    },
    {
      id: 6,
      name: 'Steel Sinks Squad',
      description: 'Installing robust sinks for industrial and commercial settings.',
      color: '#f7961e',
    },
  ];

  addTask(event: MbscCalendarEventData): void {
    const ev: MbscCalendarEvent = event.original!;
    const index = this.myEvents.findIndex((e) => e.id === ev.id);
    this.notify.prompt({
      title: 'Add new task to ' + ev.title,
      callback: (value) => {
        if (value) {
          const newEventList = [...this.myEvents];
          ev['tasks'].push(value);
          newEventList.splice(index, 1, ev);
          this.myEvents = newEventList;
          this.notify.toast({
            duration: 3000,
            message: 'Tasks updated for ' + ev.title,
          });
        }
      },
    });
  }

  ngOnInit(): void {
    this.http.jsonp<MbscCalendarEvent[]>('https://trial.mobiscroll.com/events-check-list-tasks/', 'callback').subscribe((resp) => {
      this.myEvents = resp;
    });
  }
}
